Never operate the charger if it has received a sharp blow or been dropped or damaged in any way.

Do not expose the charger to rain or excessive moisture.

For AAA batteries: Charge time in hours = the capacity of your battery ×.

For AA batteries: Charge time in hours = the capacity of your battery ×.

To calculate the charge time for your battery, based on its rated capacity, use the following formulas. Note: Batteries will not be damaged by leaving them in the charger until the timer turns it off. For batteries with less capacity, simply remove batteries before the charge cycle is complete, based on estimated charge times in the following chart. Simply reset the charger to begin a second charge cycle for batteries with larger capacities. The charger can be used to recharge Ni-Cd batteries with capacities greater than 850 mAh and Ni-MH batteries with capacities greater than 1600 mAh. Unplug the charger from the outlet, then remove the batteries or AAA battery adapter(s) from the charger.Ĭharging Batteries with Different Capacities When the batteries finish charging, the indicator turns off. The red indicator lights when you are charging Ni-Cd batteries the green indicator lights if you are charging Ni-MH batteries.Ĥ. The plug is polarized to fit in the outlet only one way. Plug the charger into a standard AC outlet. Lift the prongs of the AC plug until the plug snaps into place.

#Radio shack battery charger 23 1303 manual install

Note: The charger does not charge if you install two AA or AAA batteries intoģ. Then install the battery adapter into BAY 1 with the battery contacts facing the top of the bay and the arrow marked on the adapter pointing To charge two Ni-Cd or Ni-MH AAA batteries, install both into the supplied AAA battery adapter as indicated by the polarity symbols (+ and –) marked on the adapter. Note: Both batteries must be installed in the same bay. To charge two Ni-Cd or Ni-MH AA batteries, install both into BAY 1 as indicated by the polarity symbols (+ and –) marked inside the compartment, then slide Ni-Cd/Ni-MH to the appropriate setting. Reverse Polarity Protection - protects the charger and batteries against damage from incorrectly installed batteries.Īutomatic Timer Shut-Off - turns off the charger to prevent overcharging the batteries.ġ. Two Charging Indicators - an indicator lights during charging for each battery type (Ni-Cd or Ni-MH), and turns off when charging is complete. Remove at least one of the batteries and the light will go off.Your RadioShack Compact Ni-Cd (nickel cadmium)/Ni-MH (nickel metal hydride) Battery Charger is designed to charge two or four batteries - AA and AAA types. The red light remains on when the charger is unplugged.

Leave the batteries in the charger, while the light continues to blink red, for about 24 hours.

If the light blinks red in about 90 seconds after battery insertion, then the battery voltage is too low. If charging is needed, briefly drain the batteries before trying again.

#Radio shack battery charger 23 1303 manual full

This indicates that the battery already have a full charge. There are several ways to restore batteries that cannot be charged by the charger.If the light blinks red within five seconds after battery insertion, then the battery voltage is too high. Occasionally, the charger might show blinking red right to indicate bad batteries. Rescuing “bad batteries” indicated by a blinking red light. The charger has a built-in converter circuitry that will become warm during rapid charging. It is normal for the charger to become warm while rapid charging. This does not mean the batteries are charged faster than others or overcharged The two batteries will become warmer than the other batteries due to heat generated by a converter circuitry in the charger. It is normal for the two rear batteries to become warmer than the other banks.
